This program calculates the effects of the impact of an object (metor, asteroid or comet) hitting the Earth. To operate the calculator, enter desired values to describe an impactor and press the Calculate button. You may change any input value and recalculate. To clear the input windows, press the Clear button.



Impactor data

Diameter Meters
Density Grams/cubic centimeter
Velocity Kilometers/second
Graze angle Degrees from horizontal











Impactor Parameters

Volume Cubic meters
Kinetic energy Joules
Mass Kilograms
Equivalent yield Kilotons of TNT







Crater Parameters

Actual diameter Meters
Actual depth Meters
Volume Cubic meters
Apparent diameter Meters
Apparent depth Meters
Ejecta spread Meters





Notes

When an asteroid or comet impacts the Earth, the energy released mainly depends on the mass and velocity of the impactor. Mass is determined by the volume and density of the object. Below is a table of some information known about several of the largest asteroids:



Asteroid name

Density - g/cc

Diameter - km

1 Ceres

2.05 ± 0.05

466

2 Pallas

4.2 ± 0.3

261

4 Vesta

4.3 ± 0.3

262.5

16 Psyche

1.8 ± 0.6

132

243 Ida

2.7 ± 0.4*

58 x 23

253 Mathilde

1.3 ± 0.2

28.5 x 25

433 Eros

2.67 ± 0.03

17.5 x 6.5



For comparison, the density of water is 1 g/cc, rock about 2 g/cc, and iron about 7 g/cc.

For velocity of an object at impact, consider that the Earth's escape velocity is 11 km/sec. An object falling toward the Earth from a large distance (well beyond the Moon) and starting from rest would be moving at close to this velocity on impact.

Also, the Earth is moving at about 30 km/sec in its orbit about the Sun; an object moving in the opposite direction might impact at more than twice this velocity. Try investigating the other components of the Earth's velocity through cosmic space.

Some current information about actual threats to the Earth can be found here: NASA/JPL Near-Earth Object Program
